Vent-A-Hood® Contemporary Series 36” Panel Ready Wall Mount Range Hood
At a Glance
This wall mounted range hood creates a "one of a kind statement" in the kitchen. It is available with brass, copper, stainless steel, or mirror stainless steel lip treatment. Hood only available in stainless steel. Simply select the model you need, and then specify the lip treatment finish.
Proposition 65 Warning for California Residents
Construction
| Chimney | Fixed |
|---|
Display
| Controls | Mechanical |
|---|
Dimensions
| Max Height Above Cooktop | 24 |
|---|---|
| Min Height Above Cooktop | 24 |
Other
| Number of Lights | 2 |
|---|---|
| Air Mover(s) Speed | 1550 |
| Number of Air Movers | 2 |
Misc. Specs
| Width (in.) | 36 |
|---|---|
| Height (in.) | 12 |
| Duct Size (in.) | 8 |
| Depth (in.) | 21 |
| Collection | Contemporary Series |
| Appliance Color | Panel Ready |
| Positioning | Stationary |
| Manufacturer Warranty | 1 Year |
| Color Finish Name | Panel Ready |
| Commercial Use Approved | No |
| Range Hood Type | Wall Mounted |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Outdoor Approved | No |
| Appliance Fit Width (in.) | 36 |
| Smart Compatible | No |
| Wifi Capable | No |
| Maximum CFM | 600 |
| Ductless Capable | No |
| Bulb Type | Halogen |
| App Capable | No |
| Heat Sensor | No |
| Charcoal Filter | No |
| Filter Indicator Light | No |
| Sones Rating | 6.5 |
| Height Above Cooktop | 24 |
| Voltage | 115 |
| Range Hood Features | Light |
Vent-A-Hood® Contemporary Series 36” Panel Ready Wall Mount Range Hood
Model #: XLH12-236B SS
At a Glance
Get to know this product.
In addition, you may specify the optional finished round duct with optional square or round duct collars or the optional square duct cover. Shown with matching finished round duct and round duct collars (sold separately). Square duct collars are also available (sold separately). Also available with 10" x 10" square duct covers (sold separately). Finished round duct and square duct covers are available in standard sizes for 7', 8', and 9' ceiling heights or in custom sizes.
The Unique Magic Lung®
Our patented technology keeps your kitchen running smoothly.
The patented Magic Lung® blower system sets Vent-A-Hood® apart.
You shouldn't settle for anything less than the Magic Lung® because it is quite, efficient, easy-cleaning, fire-safe, and powerful.
Vent-A-Hood's® Magic Lung® "multi-blower technology" allows CFM to double, triple, or quadruple with very little effect on sound levels.
Halogen Lights
Standard in all models. 50-watt halogen lights come with a dual switch for dimming to 25 watts. Bulbs included. For hoods 24" to 41" wide, two lights; 42" to 53" wide, three lights; 54" to 66" wide, four lights. Each island hood has four halogen lights— one in each corner.
Additional Features:
600 CFM
Equivalent to 900 CFM power
Halogen lighting
Quietest hood in the industry
Available in several finish options
Mounts 24" above cooking surface
Fits 8" round duct
Available In Various Colors
Vent-A-Hood® K-Series Warranty
The warranty for Vent-A-Hood® K-Series products is one year from the date of purchase.
The warranty does not cover: freight damage, blower wheel damage, light bulbs, damage or malfunction caused by poor installation, incidental or consequential damage, commercial application, misapplication or modification of or to any part of the Vent-A-Hood® product
